Smoke Systems EL Telemetry Bridge V6 1-Pack
Smoke Systems EL Telemetry Bridge V6 1-Pack
The Telemetry Bridge V6 connects Jeti-compatible sensors to the PowerBox CORE telemetry bus. It supports the unencrypted EX-BUS or Jeti EX protocols, allowing a wide range of telemetry-capable devices to be integrated. Setup is straightforward: connect the bridge to the CORE, scan for the sensor, and configure the display. A maximum of 15 values per sensor can be shown with adjustable thresholds and alarms.
Compatible with tested sensors including Jeti Master Spin PRO, YGE 165HVT, Jeti CentralBox, and many more. Note that GPS and date/time values are not supported.
Key Features
| Brand | Smoke Systems EL |
| Product Type | Telemetry Bridge |
| Model | V6 |
| Compatibility | PowerBox CORE (P²-Bus) |
| Supported Protocols | Unencrypted EX-BUS, Jeti EX, Simple Text |
| Maximum Sensor Values Displayed | 15 per sensor |
| Connection | Fixed cable to P² bus |
| Emulator | JetiBOX (since version 6.0) |
| Not Supported | GPS and date/time values |
Compatibility
Compatible with PowerBox CORE and Jeti-compatible sensors supporting unencrypted EX-BUS or Jeti EX protocols. Tested sensors include Jeti Master Spin PRO, YGE 165HVT, Jeti CentralBox, Jeti MBar, Jeti MT300 EX, Jeti Malti, Jeti MRPM, Jeti MU3, Jeti SBEC30, SmokeDriver, Kontronik TelME Jeti, JetCat PRO-Interface, Jeti MainSwitch 100/200, Jeti MSpeed, JetCat ECU-V12, Jeti MaxBec 2D plus, and Altis V4+.
How to use
Connect the Telemetry Bridge to the PowerBox CORE via the fixed cable. On the CORE, tap and hold the display, then press [Rescan sensors] to detect the bridge. To read sensor data, initiate a scan from the bridge. Finally, select up to 15 values to display and set thresholds as needed.
What's included
- 1x Telemetry Bridge V6
- Fixed connection cable
