The PowerBox Digi Switch V2 is a second-generation electronic switch designed for small to medium-sized models. Its compact format and versatile performance have made it a standard in the industry for nearly fifteen years.
Featuring a machined and anodized aluminum case for improved cooling, this switch offers a 20% higher continuous current capacity and can handle peak loads over 10A. It provides four user-selectable output voltages, including regulated 6.0V, 7.0V, and 7.6V for HV servos, as well as an unregulated option, and supports LiPo, LiIon, LiFePo, and NiMH batteries.
Key Features
| Operating Voltage | 4.0V - 9.0V |
| Power Supply | 2s LiPo, 2s LiIon, 2s LiFePo, 5s NiMH |
| Current Drain (Power-on State) | 23 mA |
| Current Drain (Standby) | 4 μA |
| Maximum Load Current | max. 10 A |
| Drop-out Voltage | 0.1 V |
| Output Voltage | 6.0 V / 7.0 V / 7.6 V stabilised or non-regulated |
| Dimensions | 1.97 x 0.71 x 0.43 in |
| Weight | 0.53 oz |
| Temperature Range | -22 °F to +167 °F |
| Brand | PowerBox |
| Product Type | Electronic Switch |
| Material | Aluminum (case) |
Highlights
- Second generation compact electronic switch
- Machined and anodized aluminum case for improved cooling
- 20% higher continuous current capacity than previous version
- User-selectable output voltages: 6.0V, 7.0V, 7.6V, or unregulated
- RGB LED battery voltage indicator
- Telemetry support for CORE systems
